Toshiba TOSVERT VF-AS3 User Manual

E6582062
9. Measures to satisfy standards 9-8
9
Voltage
class
Applicable
motor
[kW]
Inverter type
Output
current
*1
AIC (A)
(Interrupting
capacity)
Fuse class and
current (A)
Power wire
sizes
*2
Grounding
wire sizes
*2
3-phase
240 V
0.75 VFAS3-2004P
4.6
<F300>="4"
AIC 5000A J 6Amax. AWG 14 AWG 14
1.5 VFAS3-2007P
8.0
<F300>="4"
AIC 5000A J 10Amax. AWG 14 AWG 14
2.2 VFAS3-2015P
11.2
<F300>="4"
AIC 5000A J 15Amax. AWG 14 AWG 14
4.0 VFAS3-2022P
18.7
<F300>="4"
AIC 5000A J 25A max. AWG 10 AWG 12
5.5 VFAS3-2037P
25.4
<F300>="4"
AIC 5000A J 35Amax. AWG 8 AWG 10
7.5 VFAS3-2055P
32.7
<F300>="4"
AIC 5000A J 45Amax. AWG 8 AWG 10
11 VFAS3-2075P
46.8
<F300>="4"
AIC 5000A J 60Amax. AWG 6 AWG 10
15 VFAS3-2110P
63.4
<F300>="4"
AIC 5000A J 90Amax. AWG 4 AWG 10
18.5 VFAS3-2150P
78.4
<F300>="4"
AIC 5000A J 110Amax. AWG 2 AWG 8
22 VFAS3-2185P
92.6
<F300>="4"
AIC 5000A J 125Amax. AWG 1 AWG 8
30 VFAS3-2220P
123.0
<F300>="2.5"
AIC 5000A J 150Amax. AWG 2/0 AWG 6
37 VFAS3-2300P
149.0
<F300>="2.5"
AIC 5000A J 175Amax. AWG 3/0 AWG 6
45 VFAS3-2370P
176.0
<F300>="2.5"
AIC 10000A J 225Amax. 250MCM AWG 6
55 VFAS3-2450P
211.0
<F300>="2.5"
AIC 10000A
AR 315Amax.
AWG 2/0 × 2
*3 *4
AWG 6
*3 *4
75 VFAS3-2550P
282.0
<F300>="2.5"
AIC 10000A
AR 350Amax.
AWG 3/0 × 2
*3 *4
AWG 4
*3 *4
3-phase
480 V
0.75 VFAS3-4004PC
2.2
<F300>="4"
AIC 5000A J 3Amax. AWG 14 AWG 14
1.5 VFAS3-4007PC
4.0
<F300>="4"
AIC 5000A J 6Amax. AWG 14 AWG 14
2.2 VFAS3-4015PC
5.6
<F300>="4"
AIC 5000A J 10Amax. AWG 14 AWG 14
4.0 VFAS3-4022PC
9.3
<F300>="4"
AIC 5000A J 15Amax. AWG 14 AWG 14
5.5 VFAS3-4037PC
12.7
<F300>="4"
AIC 5000A J 15Amax. AWG 12 AWG 14
7.5 VFAS3-4055PC
16.5
<F300>="4"
AIC 5000A J 20Amax. AWG 10 AWG 14

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
