E6582062
2-19 2. Installation and wiring
2
3
9
10
Wiring duct and Duct cover
1 Remove the front cover (lower) and the transparent cover.
Refer to the procedure above.
2 Remove two screws of Duct cover.
Store Duct cover and screws so as not to be lost.
3 Remove two nuts of the wiring duct.
Store the removed nuts so as not to be lost.
Wiring ductand
Duct cover
Screw
Nut
