12. Specifications 12-2
9
12
< 240 V class: ND rating >
Item Specification
Voltage class 240 V class
Frame size A1 A2 A3 A4 A5 A6
Applicable motor (kW) 0.75 1.5 2.2 4.0 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Applicable motor (HP) 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100
Rating
Type VFAS3-
Form
2004P 2007P 2015P 2022P 2037P 2055P 2075P 2110P 2150P 2185P 2220P 2300P 2370P 2450P 2550P
Output capacity (kVA)
*1
*1 Capacity is calculated at 220 V for the 240 V class.
1.8 3.0 4.3 7.1 9.7 12.5 17.8 24.2 29.9 35.3 46.9 56.8 67.1 80.4 107
Output current (A)
*2
*2 Indicates rated output current when setting <F300: Carrier frequency> into 4 kHz for frame size A1 to A5, 2.5 kHz for frame size A6.
4.6 8.0 11.2 18.7 25.4 32.7 46.8 63.4 78.4 92.6 123 149 176 211 282
Output voltage 3-phase 200 V to 240 V (The maximum output voltage is equal to the input supply voltage)
Overload current rating 120%-1 minute, 135%-2 s
Electrical
braking
Dynamic braking circuit Built-in Optional
Dynamic braking resistor External braking resistor (Optional)
Power supply
Voltage-frequency 3-phase 200 V to 240 V - 50/60 Hz
Allowable fluctuation
Voltage 170 V to 264 V
*3
, Frequency ± 5%
*3 Lower limit of voltage for 240 V class is 180 V when the inverter is used continuously (load of 100%).
Required power supply
capacity (kVA)
*4
*4 Required power supply capacity varies with the value of the power supply side inverter impedance (including those of the input reactor and wires).
1.2 2.3 3.3 5.9 7.8 10.3 15.0 20.6 24.9 29.4 40.5 49.3 59.6 73.3 98.1
Degree of protection (IEC60529) IP20 IP00
Cooling method Forced air-cooled
Cooling fan noise (dBA)
(Reference value)
*5
*5 These acoustic noise values are not guaranteed because they are just reference values.
58 54 60 64 63 70
Color RAL7016 / RAL7035
EMC filter No EMC filter
DC reactor Built-in
UL type1 kit Built-in Optional
To Next Page
