E6582062
12. Specifications 12-6
9
12
*1. Capacity is calculated at 440 V for the 480 V class.
*2. Indicates rated output current when setting <F300: Carrier frequency> into 4 kHz for frame size A1 to A5, 2.5 kHz for frame size A6 to A8.
*3. Lower limit of voltage for 480 V class is 342 V when the inverter is used continuously (load of 100%).
*4. Required power supply capacity varies with the value of the power supply side inverter impedance (including those of the input reactor and wires).
*5. These acoustic noise values are not guaranteed because they are just reference values.
Item Specification
Voltage class 480 V class
Frame size A5 A6 A7 A8
Applicable motor (kW) 55 75 90 110 132 160 220 250 280 315
Applicable motor (HP) 75 100 125 150 200 250 350 400 450 500
Rating
Type VFAS3-
Form 4450PC 4550PC 4750PC 4900PC 4110KPC 4132KPC 4160KPC 4200KPC 4220KPC 4280KPC
Output capacity (kVA)
*1
80.8 111 132 161 191 230 325 367 419 469
Output current (A)
*2
106 145 173 211 250 302 427 481 550 616
Output voltage 3-phase 380 V to 480 V (The maximum output voltage is equal to the input supply voltage)
Overload current rating 120%-1 minute, 135%-2 s
Electrical
braking
Dynamic braking circuit Built-in Optional Built-in Optional
Dynamic braking resistor External braking resistor (Optional)
Power supply
Voltage-frequency 3-phase 380 V to 480 V - 50/60 Hz
3-phase 380 to 440 V - 50 Hz,
3-phase 380 to 480 V - 60 Hz
Allowable fluctuation
Voltage 323 V to 528 V
*3
, Frequency ± 5%
Voltage 323 to 484 V - 50 Hz,
323 V to 528 V - 60 Hz
*3
,
Frequency ± 5%
Required power supply
capacity (kVA)
*4
77.0 103 125 155 181 214 296 335 379 422
Degree of protection (IEC60529) IP20 IP00
Cooling method Forced air-cooled
Cooling fan noise (dBA)
(Reference value)
*5
63 70 73 76
Color RAL7016 / RAL7035
EMC filter Built-in
DC reactor Built-in Attached
UL type1 kit Built-in Optional -
