Toshiba TOSVERT VF-S11 User Manual

E6581158
F-32
6
[Parameter setting]
Title Function Adjustment range Default setting
H
PWM carrier frequency 2.0-16.0 (kHz) (*) 12.0
H
Random mode 0: Disabled, 1: Enabled 0
H
Carrier frequency control mode
selection
0: Carrier frequency not reduced
automatically
1: Carrier frequency reduced
automatically
2: Carrier frequency not reduced
automatically
Support for 400V models
3: Carrier frequency reduced
automatically
Support for 400V models.
1
* Load reduction will be required if the PWM carrier frequency is modified for each applicable motor model.
Refer to the following table.
Load reduction ratios required.
[200V Class]
Carrier frequency
VFS11S-
VFS11-
4kHz or less 12kHz or less 16kHz or less
2002PL/M 1.5A 1.5A 1.5A
2004PL/M 3.3A 3.3A 3.3A
2005PM 3.7A 3.3A 3.2A
2007PL/M 4.8A 4.4A 4.2A
2015PL/M 8.0A 7.9A 7.1A
2022PL/M 11.0A 10.0A 9.1A
2037PM 17.5A 16.4A 14.6A
2055PM 27.5A 25.0A 25.0A
2075PM 33.0A 33.0A 29.8A
2110PM 54.0A 49.0A 49.0A
2150PM 66.0A 60.0A 54.0A
[400V Class]
Input
voltage
480V or less more than 480V
Carrier frequency Carrier frequency
VFS11-
4kHz or less 12 kHz or less 16kHz or less 4kHz or less 12kHz or less 16kHz or less
4004PL 1.5A 1.5A 1.5A 1.5A 1.5A 1.2A
4007PL 2.3A 2.1A 2.1A 2.1A 1.9A 1.9A
4015PL 4.1A 3.7A 3.3A 3.8A 3.4A 3.1A
4022PL 5.5A 5.0A 4.5A 5.1A 4.6A 4.2A
4037PL 9.5A 8.6A 7.5A 8.7A 7.9A 6.9A
4055PL 14.3A 13.0A 13.0A 13.2A 12.0A 12.0A
4075PL 17.0A 17.0A 14.8A 15.6A 14.2A 12.4A
4110PL 27.7A 25.0A 25.0A 25.5A 23.0A 23.0A
4150PL 33.0A 30.0A 26.0A 30.4A 27.6A 24.0A

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
