Toshiba TOSVERT VF-S11 - 11.3 Extended parameters

E6581158
K-4
11
11.3 Extended parameters
• Input/output parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
H
0100 Low-speed signal
output frequency
Hz 0.1/0.01 0.0-HJ 0.0 6.1.1
H
0101 Speed reach
setting frequency
Hz 0.1/0.01 0.0-HJ 0.0 6.1.3
H
0102 Speed reach
detection band
Hz 0.1/0.01 0.0-HJ 2.5 6.1.2
H
0105 Priority selection
(Both F-CC and
R-CC are ON)
--
0: Reverse
1: Slowdown Stop
1 6.2.1
0: Analog input for communications
VIB - analog input
1: VIA - analog input
VIB - contact input (Sink)
2: VIA - analog input
VIB - contact input (Source)
3: VIA - contact input (Sink)
VIB - contact input (Sink)
H
0109 Analog/contact in-
put function selec-
tion (VIA/VIB ter-
minal)
--
4: VIA - contact input (Source)
VIB - contact input (Source)
0 6.2.2
H
0110 Always-active
function selection
- - 0-64 (ST) 1 6.3.1
H
0111 Input terminal
selection 1 (F)
- - 0-64 (F) 2
H
0112 Input terminal
selection 2 (R)
- - 0-64 (R) 3
H
0113 Input terminal
selection 3 (RES)
- - 0-64 (RES) 10
H
0114 Input terminal
selection 4 (S1)
- - 0-64 (SS1) 6
H
0115 Input terminal
selection 5 (S2)
- - 0-64 (SS2) 7
H
0116 Input terminal
selection 6 (S3)
- - 0-64 (SS3) 8
H
0117 Input terminal
selection 7 (VIB)
- - 5-17 (SS4) 9
H
0118
Input terminal
selection 8 (VIA)
--
5-17 (AD2) 5
6.3.2
H
0130
Output terminal
selection 1A
(RY-RC)
--
0-255 (RCH) 4
H
0131 Output terminal
selection 2A
(OUT-NO)
- - 0-255 (LOW) 6
H
0132 Output terminal
selection 3 (FL)
- - 0-255 (FL) 10
H
0137 Output terminal
selection 1B
(RY-RC)
- - 0-255 (always ON) 255
H
0138 Output terminal
selection 2B
(OUT-NO)
- - 0-255 (always ON) 255
6.3.3
