Toshiba TOSVERT VF-S11 User Manual

E6581158
C-2
3
3.1 Simplified Operation of the VF-S11
The procedures for setting operation frequency and the methods of operation can be selected from the following.
Start / Stop
:
(1) Start and stop using the operation panel keys
(2) Run and stop from the operation panel
Setting the frequency
:
(1) Setting using the potentiometer on the inverter
main unit
(2) Setting using the operation panel
(3) Setting using external signals to the terminal board
(0-10Vdc, 4-20mAdc)
Use the basic parameters EOQF (Operation command mode selection),
HOQF (Speed setting mode selection).
Title Function Adjustment range Default setting
EOQF Command mode selection
0: Terminal board
1: Panel
1
HOQF Frequency setting mode
0: Internal potentiometer setting
1: VIA
2: VIB
3: Operation panel
4: Serial communication
5: External contact up/down
6: VIA+VIB (Override)
0
* See 5.4 for HOQF=,  and .

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
