11. Table of parameters and data
11.1 User parameters
Title Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range Default setting
User
setting
Refer-
ence
HE
Operation fre-
quency of opera-
tion panel
Hz 0.1/0.01 NN-WN 0.0 3.2
11.2 Basic parameters
• Four automatic functions or basic parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
CWJ
- History function - - Displays parameters in groups of five
in the reverse order to that in which
their settings were changed.
* (Possible to edit)
- 4.1.4
CW
0000 Automatic
acceleration/decel
eration
- - 0: Disabled (manual)
1: Automatic
2: Automatic (only at acceleration)
0 5.1.1
CW
0001 Automatic torque
boost
- - 0: Disabled
1: Automatic torque boost + auto-
tuning
2: Vector control + auto-tuning
3: Energy saving + auto-tuning
05.2
CW
0040 Automatic function
setting
- - 0: Disabled
1: Coast stop
2: 3-wire operation
3: External input UP/DOWN setting
4: 4-20 mA current input operation
05.3
EOQF
0003 Command mode
selection
- - 0: Terminal board
1: Operation panel
15.4
HOQF
0004 Frequency setting
mode selection 1
- - 0: Built-in potentiometer
1: VIA
2: VIB
3: Operation panel
4: Serial communication
5: UP/DOWN from external contact
6: VIA + VIB (Override)
05.4
6.5.1

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
