Table 1 EMC standards
Category Subcategory
Product stan-
dards
Test standard and level
Radiation noise CISPR/B/276/DC Class A Group 1
Emission
Transmission noise CISPR/B/276/DC Class A Group 1
Static discharge IEC61000-4-2
Radioactive radio-frequency mag-
netic contactor field
IEC61000-4-3
First transient burst IEC61000-4-4
Lightning surge IEC61000-4-5
Radio-frequency induc-
tion/transmission interference
IEC61000-4-6
Immunity
Voltage dip/Interruption of power
IEC 61800-3
IEC61000-4-11
Emission standards other than the above are applied to inverters when used in a commercial environment but not
an industrial environment.
Category Subcategory
Product stan-
dards
Test standard and level
Radiation noise
CISPR/B/276/DC Class B Group 1
Emission
Transmission noise
IEC 61800-3
CISPR/B/276/DC Class B Group 1
9.1.2 Measures to satisfy the EMC directive
This subsection explains what measures must be taken to satisfy the EMC directive.
(1) Insert a recommended EMI filter (Table 2) on the input side of the inverter to reduce and transmission noise
and radiation noise from input cables.
In the combinations listed in Table 2, Inverters are tested in these combination to see if they comply with
transmission noise standards. For inverters used in Japan, it is recommended to use the NF series of noise
filters.
Table 2 lists noise filters recommended for the inverters.

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
