Toshiba TOSVERT VF-S11 User Manual

E6581158
K-13
11
• Communication parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
H
0800
Communication
band speed
- - 0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
3
H
0801
Parity - - 0: NON (No parity)
1: EVEN (Even parity)
2: ODD (Odd parity)
1
H
0802
Inverter number - 1/1 0-255 0
H
0803
Communication
error trip time
s 1/1 0: (disabled)
1-100
0
H
0805
Communication
waiting time
s 0.01/0.01 0.00-2.00 0.00
H
0806
Setting of master
and slave
inverters for
communication
between inverters
(setting of master
and slave)
- - 0: Slave inverter (0 Hz command is-
sued in case the master inverter
fails)
1: Slave inverter (Operation contin-
ued in case the master inverter
fails)
2: Slave inverter (Emergency stop
tripping in case the master inverter
fails)
3: Master inverter (transmission of
frequency commands)
4: Master inverter (transmission of
output frequency signals)
0
6.22
H
0811
Point 1 setting % 1/1 0-100 0
H
0812
Point 1 frequency Hz 0.1/0.01 0.0-500.0 0.0
H
0813
Point 2 setting % 1/1 0-100 100
H
0814
Point 2 frequency Hz 0.1/0.01 0.0-500.0 50.0 (WP)
60.0
(WN, AN)
6.5.2
H
0829
Selection of
communication
protocol
- - 0: Toshiba inverter protocol
1: Modbus RTU protocol
0
H
0870
Block write data 1 - - 0
H
0871
Block write data 2 - -
0: No selection
1: Command information 1
2: Command information 2
3: Frequency command
4: Output data on the terminal board
5: Analog output for communications
0
H
0875
Block read data 1 - - 0
H
0876
Block read data 2 - - 0
H
0877
Block read data 3 - - 0
H
0878
Block read data 4 - - 0
H
0879
Block read data 5 - -
0: No selection
1: Status information
2: Output frequency
3: Output current
4: Output voltage
5: Alarm information
6: PID feedback value
7: Input terminal board monitor
8: Output terminal board monitor
9: VIA terminal board monitor
10: VIB terminal board monitor
0
H
0880
Free notes - 1/1 0-65535 0
6.22
H
0890
Parameter for op-
tion 1
- 1/1 0-65535 0 6.23
H
0891
Parameter for op-
tion 2
- 1/1 0-65535 0

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
