Toshiba TOSVERT VF-S11 - 5.8 Maximum frequency; 5.9 Upper limit and lower limit frequencies

E6581158
E-15
5
+ The inverter was factory-configured by default so that shorting terminals F-CC and terminals R-CC si-
multaneously would cause the motor to slow down to a stop. Using parameter H, however, you
can choose between stop and reverse run.
Using the parameter H, however, you can select between forward run and reverse run.
+ This function is valid only when EOQF is set to  (operation panel).
5.8 Maximum frequency
HJ: Maximum frequency
• Function
1) Programs the range of frequencies output by the inverter (maximum output values).
2) This frequency is used as the reference for acceleration/deceleration time.
Output frequency
(Hz)
When HJ
=80Hz
When HJ=60Hz
80Hz
60Hz
0 100% Frequency setting signal (%)
ȷThis function determines the value
in line with the ratings of the motor
and load.
ȷMaximum frequency cannot be
adjusted during operation.To
adjust, first stopthe inverter.
+ If HJ is increased, adjust the upper limit frequency WN as necessary.
Q Parameter setting
Title Function Adjustment range Default setting
HJ
Maximum frequency 30.0-500.0 (Hz) 80.0
5.9 Upper limit and lower limit frequencies
WN
: Upper limit frequency
NN
: Lower limit frequency
• Function
Programs the lower limit frequency that determines the lower limit of the output frequency and the upper
limit frequency that determines the upper limit of that frequency.
