12. Specifications
12.1 Models and their standard specifications
Q Standard specifications
Item Specification
Input voltage 3-phase 200V
Applicable motor (kW) 0.2 0.4 0.55 0.75 1.5 2.2 3.7 5.5 7.5 11 15
Type VFS11
Form 2002PM 2004PM 2005PM 2007PM 2015PM 2022PM 2037PM 2055PM 2075PM 2110PM 2150PM
Capacity (kVA) Note 1) 0.6 1.3 1.4 1.8 3.0 4.2 6.7 10 13 21 25
Rated output/current
(A) Note 2)
1.5
(1.5)
3.3
(3.3)
3.7
(3.3)
4.8
(4.4)
8.0
(7.9)
11.0
(10.0)
17.5
(16.4)
27.5
(25.0)
33
(33)
54
(49)
66
(60)
Output voltage Note 3) 3-phase 200V to 240V
Rating
Overload current rating 150％-60 seconds, 200%-0.5 second (50%-reduction value)
Voltage-frequency 3-phase 200V to 240V - 50/60Hz
Power
supply
Allowable fluctuation Voltage + 10%, -15% Note 4), frequency ±5%
Protective method IP20 Enclosed type (JEM1030)
Cooling method Self-cooling Forced air-cooled
Color Munsel 5Y+8/0.5
Built-in filter Basic filter
Item Specification
Input voltage 1-phase 200V 3-phase 400V
Applicable motor (kW) 0.2 0.4 0.75 1.5 2.2 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15
Type VFS11S VFS11
Form 2002PL 2004PL 2007PL 2015PL 2022PL 4004PL 4007PL 4015PL 4022PL 4037PL 4055PL 4075PL 4110PL 4150PL
Capacity (kVA) Note 1) 0.6 1.3 1.8 3.0 4.2 1.1 1.8 3.1 4.2 7.2 11 13 21 25
Rated output current
(A) Note 2)
1.5
(1.5)
3.3
(3.3)
4.8
(4.4)
8.0
(7.9)
11.0
(10.0)
1.5
(1.5)
2.3
(2.1)
4.1
(3.7)
5.5
(5.0)
9.5
(8.6)
14.3
(13.0)
17.0
(17.0)
27.7
(25.0)
33
（30）
Rated output voltage Note 3) 3-phase 200V to 240V 3-phase 380V to 500V
Rating
Overload current rating
150％-60 seconds, 200%-0.5 second
(50%-reduction value)
150％-60 seconds, 200% -0.5 second (50%-reduction value)
Voltage-current 1-phase 200V to 240V – 50/60Hz 3-phase 380V to 500V - 50/60Hz
Power
supply
Allowable fluctuation
Voltage + 10％、-15％ Note 4),
frequency±5％
Voltage + 10%, -15% Note 4), frequency ±5%
Protective method, IP20 Enclosed type (JEM1030) IP20 Enclosed type (JEM1030)
Cooling method Self-cooling
Forced air-
cooled
Forced air-cooled
Color Munsel 5Y+8/0.5 Munsel 5Y+8/0.5
Built-in filter EMI filter EMI filter
Note 1. Capacity is calculated at 220V for the 200V models and at 440V for the 400V models.
Note 2. Indicates rated output current setting when the PWM carrier frequency (parameter F300) is 4kHz or less. When ex-
ceeding 4kHz, the rated output current setting is indicated in the parentheses. It needs to be further reduced for PWM
carrier frequencies above 12 kHz.
The rated output current is reduced even further for 400V models with a supply voltage of 480V or more.
The default setting of the PWM carrier frequency is 12kHz.
Note 3. Maximum output voltage is the same as the input voltage.
Note 4. ±10% when the inverter is used continuously (load of 100%).

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
