E6581158
J-1
10
10. Peripheral devices
Danger
Mandatory
When using switchgear for the inverter, it must be installed in a cabinet.
Failure to do so can lead to risk of electric shock and can result in death or serious injury.
Prohibited
Connect earth cables securely.
Failure to do so can lead to risk of electric shock or fire in case of a failure or short-circuit or electric
leak.
10.1 Selection of wiring materials and devices
Wire size (See Note 4)
Voltage class
Capacity of
applicable
motor (kW)
Inverter model
Main circuit
(mm
2
) (See Note 1.)
DC reactor
(optional) (mm
2
)
Braking resistor/
Braking unit
(optional) (mm
2
)
Earth cable
(mm
2
)
0.2 VFS11S-2002PL 2.0 2.0 2.0 3.5
0.4 VFS11S-2004PL 2.0 2.0 2.0 3.5
0.75 VFS11S-2007PL 2.0 2.0 2.0 3.5
1.5 VFS11S-2015PL 2.0 2.0 2.0 3.5
Single-phase
200V class
2.2 VFS11S-2022PL 2.0 3.5 2.0 3.5
0.2 VFS11-2002PM 2.0 1.25 2.0 3.5
0.4 VFS11-2004PM 2.0 1.25 2.0 3.5
0.55 VFS11-2005PM 2.0 2.0 2.0 3.5
0.75 VFS11-2007PM 2.0 2.0 2.0 3.5
1.5 VFS11-2015PM 2.0 2.0 2.0 3.5
2.2 VFS11-2022PM 2.0 2.0 2.0 3.5
3.7 VFS11-2037PM 5.5 5.5 2.0 3.5
5.5 VFS11-2055PM 5.5 8.0 5.5 5.5
7.5 VFS11-2075PM 8.0 14 5.5 8.0
11 VFS11-2110PM 14 14 5.5 14
Three-phase
200V class
15 VFS11-2150PM
14×214×2
5.5 22
0.4 VFS11-4004PL 2.0 2.0 2.0 3.5
0.75 VFS11-4007PL 2.0 2.0 2.0 3.5
1.5 VFS11-4015PL 2.0 2.0 2.0 3.5
2.2 VFS11-4022PL 2.0 2.0 2.0 3.5
3.7 VFS11-4037PL 2.0 2.0 2.0 3.5
5.5 VFS11-4055PL 2.0 3.5 2.0 3.5
7.5 VFS11-4075PL 3.5 5.5 2.0 3.5
11 VFS11-4110PL 5.5 8.0 2.0 5.5
Three-phase
400V class
15 VFS11-4150PL 8.0 14 2.0 8.0
Note 1: Sizes of the wires connected to the input terminals R, S and T and the output terminals U, V and W when
the length of each wire does not exceed 30m.
Note 2: For the control circuit, use shielded wires 0.75 mm
2
or more in diameter.
Note 3: For grounding, use a cable with a size equal to or larger than the above.
Note 4: The wire sizes specified in the above table apply to HIV wires (cupper wires shielded with an insulator
with a maximum allowable temperature of 75°C) used at an ambient temperature of 50°C or less.
