Toshiba TOSVERT VF-S11 - 6.9 Jog run mode

E6581158
F-28
6
6.9 Jog run mode
H : Jog run frequency
H
: Jog run stopping pattern
H
: Panel jog run mode
• Function
Use the jog run parameters to operate the motor in jog mode. Input of a jog run signal fenerates a jog
run frequency output at once, irrespective of the designated acceleration time.
Also, you can choose an operation panel start/stop mode between the ordinary start/stop mode and the
jog run start/stop mode.
The jog run function needs to be assigned to an input terminal. When assigning it to the RES terminal, set
H to .
The motor can be operated in jog mode while the jog run setting terminals are connected (RES-CC ON). (Setting
H to .)
[Parameter setting]
Title Function Adjustment range Default setting
H Jog run frequency H-20.0 (Hz) 5.0
H
Jog run stopping
pattern
0: Slowdown stop
1: Coast stop
2: DC braking
0
H
Panel jug run mode
0: Disabled
1: Panel jog run mode enabled
0
[Setting of jog run setting terminal (RES-CC)]
Assign control terminal RES ([4: reset signal] in default setting) as the jog run setting terminal.
Title Function Adjustment range Default setting
H
Input terminal selection (RES) 0-64
4
(jog run setting
terminal)
Note 1: During the jog run mode, there is LOW (low speed detection signal) output but no RCH (designated
frequency reach signal) output, and PID control does not work.
Note 2: When the operation panel only is used for operation in jog run mode, the jog run function does not need to
be assigned to any input terminal.
