Toshiba TOSVERT VF-S11 User Manual

E6581158
A-3
1
1.2 Contents of the product
Here is explained the type and form written on the label.
Type Form
VFS11S - 2007PLE- WN -A22
Model name
TOSVERT
VF-S11series
Number of
power phases
S: sin
g
le-phase
None:
three-phase
Applicable motor
capacity
002 : 0.2kW
004 : 0.4kW
005 : 0.55kW
007 : 0.75kW
015 : 1.5kW
022 : 2.2kW
037 : 3.7kW
055 : 5.5kW
075 : 7.5kW
110 : 11kW
150 : 15kW
Additional functions I
L: With a built-in
EMC filter
M: Standard
built-in filter
Operation panel
P: Provided
Default interface
logic*
WN, AN : Negative
WP : Positive
Special specification code
A

:

is the number
Input
(
AC
)
volta
g
e
2 : 200V ∼ 240V
4 : 380V ∼ 500V
6 : 525V ∼ 600V
Additional function II
None:
Standard product
E: Enclosed type
R: With a built-in
RS-485 device
* This code represents the factory default logic setting. You can switch from one input/output logic to the other using
slide switch SW1. (See 2.3.2)
Warning: Always shut power off first then check the ratings label of inverter held in a cabinet.

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
