6.5.2 Setting frequency command characteristics
H : VIA input point 1 setting
H
: VIA input point 1 frequency
H
: VIA input point 2 setting
H
: VIA input point 2 frequency
H
: VIB input point 1 setting
H
: VIB input point 1 frequency
H
: VIB input point 2 setting
H
: VIB input point 2 frequency
H
: Point 1 setting
H
: Point 1 frequency
H
: Point 2 setting
H
: Point 2 frequency
• Function
These parameters adjust the output frequency according to the externally applied analog signal (0-
10Vdc voltage, 4-20mAdc current) and the entered command for setting an external contact
frequency.
