6.20 Adjustment parameters
6.20.1 Pulse train output for meters
H : Logic output/pulse train output selection (OUT-NO)
H : Pulse train output function selection (OUT-NO)
H
: Maximum nembers of pulse train
• Function
Pulse trains can be sent out through the OUT-NO output terminals.
To do so, it is necessary to select a pulse output mode and specify the number of pulses.
Ex.: When operations frequencies (0 to 60Hz) are put out by means of 0 to 600 pulses
HJ=60.0, H=1, H=0, H=600
Title Function Adjustment range Default setting
H
Logic output/pulse train output
selection (OUT-NO)
0: Logic output
1: Pulse train output
0
H
Pulse train output function selection
(OUT-NO)
0: Output frequency
1: Output current
2: Set frequency
3: DC voltage
4: Output voltage command
value
5: Input power
6: Output power
7: Torque
8: Torque current
9: Motor cumulative load factor
10:Inverter cumulative load factor
11:PBR (braking reactor) cumula-
tive load factor
12:Frequency setting value (after
PID)
13:VIA/II Input value
14:VIB Input value
15:Fixed output 1 (Output current:
100%)
16:Fixed output 2 (Output current:
50%)
17:Fixed output 3
(Other than the output current:
100%)
0
H
Maximum nembers of pulse train
500-1600 (pps)
800
Note 1: The pulse length is fixed. Therefore, the duty is variable.
Note 2: The minimum pulse output rate is 38 PPS. Keep in mind that no pulses can be put out at any rate
smaller than 38 PPS.
