E6581158
G-5
7
7.2 Setting the operation mode
Applied operation can be performed by selecting the operation mode. To set the operation mode, use the basic
parameter EOQF (command mode selection) and the input terminal selection parameter.
(1) Operation panel operation (2) Terminal board operation
RUN
STOP
RUN STOP
F
R
RES
S1
S2
S3
CC
PLC
PP
VIA
VIB
CC
F
R
RES
S1
S2
S3
CC
PLC
PP
VIA
VIB
CC
EOQF: (Operation panel) EOQF: (Terminal board)
