Toshiba TOSVERT VF-S11 User Manual

E6581158
G-4
7
(11) Switching between analog setting and preset
speed setting
(12) Switching between analog setting and terminal
setting from the operation panel
RUN
STOPRUN STOP
F
R
PLC
PP
VIA
CC
RES (FCHG)
S1
S2
S3
CC
VIB
F
R
RES
S1
S2
S3
CC
PLC
PP
VIA
VIB
CC
Voltage
signal
Voltage/current
signal
Voltage
signal
Voltage/current
signal
HOQF:  (VIA) or  (VIB)
EOQF:  (Terminal board)
H: 
To switch to preset-speed setting, use the external
terminals S1 to S3.
HOQF:  (Operation panel)
H:  (Allocation of FCHG)
To switch to H setting, enter the
command through FCHG.
H: 
H: (VIA) or  (VIB)
(13) Setting by means of a remote input device (14) Switching between remote control and local control
RUN
STOP
F
R
RES
S1
S2
S3
CC
PLC
PP
VIA
VIB
CC
F
R
RES
S1(SC/LC)
S2
S3
CC
PLC
PP
VIA
VIB
CC
RUN
STOP
Connectorforremotecontrol Connectorforremotecontrol
Communication command fa00h 14bit: 1
Priority on remote input device
(HOQFҏ: )
Communication command fa00h 14bit: 1
H:  (Allocation of SL/LC)
Switched to local when a command is entered
through SC and LC during operation by means
of a remote input device
Activated if the parameter HOQF, H or
H is so set

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
