Toshiba TOSVERT VF-S11 User Manual

E6581158
G-3
7
(7) Preset-speed (8) Voltage/current switching
RUN STOPRUN STOP
F
R
RES
S1
S2
S3
CC
PLC
PP
VIA
VIB
CC
F
R
RES
S1 (FCHG)
S2
S3
CC
PLC
PP
CC
VIA
VIB
VIA
I
Voltage

signal
Currentsignal
EOQF:  (Terminal board)
UT to UT: 1-7-speed run
H to H: 8-15-speed run
To select 7-speed run, use the terminals S1 to S3.
To select 15-speed run, allocate the input terminal
function SS4.
H:  (Automatic switching)
H:  (Forced switching of FCHG)
H:  (Allocation of FCHG)
HOQF: 
H: 
(9) Analog addition setting (10) Switching between external contact UP/DOWN
and VIA input
RUN
STOP
RUN
STOP
F
R
RES (FCHG)
S1 (Up)
S2 (Down)
S3 (Clear)
CC
PLC
PP
VIA
VIB
CC
F
R
RES
S1
S2
S3
CC
PLC
PP
VIA
VIB
CC
VIA
V
Voltage
signal
Voltage/current
signal
HOQF: (VIA+VIB)
H: 
HOF: , H: , H: 
H:  (Allocation of FCHG)
To switch to VIA setting, enter the command
through FCHG.
H:  (Allocation of UP)
H:  (Allocation of DOWN)
H:  (Allocation of CLR)

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
