E6581158
K-12
11
• Operation panel parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
H
0700
Prohibition of
change of
parameter settings
- - 0: Permitted
1: Prohibited
0 6.21.1
H
0701
Unit selection - - 0: %
1: A (ampere)/V (volt)
0 6.21.2
H
0702
Free unit selection Times 0.01/0.01 0.00: Free unit display disabled
(display of frequency)
0.01-200.0
0.00
H
0705
Inclination
characteristic of
free unit display
- - 0: Negative inclination (downward
slope)
1: Positive inclination (upward slope)
1
H
0706
Free unit display
bias
Hz 0.01/0.01 0.00-HJ 0.00
6.21.3
H
0707
Free step 1
(pressing a panel
key once)
Hz 0.01/0.01 0.00: Disabled
0.01-HJ
0.00 6.21.4
H
0708
Free step 2 (panel
display)
- 1/1 0: Disabled
1-255
0 6.21.4
H
0710
Standard monitor
display selection
- - 0: Operation frequency (Hz/free unit)
1: Frequency command (Hz/free unit)
2: Output current (%/A)
3: Inverter rated current (A)
4: Inverter load factor (%)
5: Output power (%)
6: Frequency command after PID
control (Hz/free unit)
7: Optional item specified from an
external control unit
0 6.21.5
H
0719
Canceling of
operation
command when
standby terminal
(ST) is turned off
- - 0: Operation command canceled
(cleared)
1: Operation command retained
1 6.21.6
H
0721
Panel stop pattern - - 0: Slowdown stop
1: Coast stop
0 6.21.7
H
0730
Prohibition of
frequency setting
on the operation
panel (HE)
- - 0: Permitted
1: Prohibited
0
H
0733
Panel operation
prohibition
(RUN/STOP keys)
- - 0: Permitted
1: Prohibited
0
H
0734
Prohibition of
panel emergency
stop operation
- - 0: Permitted
1: Prohibited
0
H
0735
Prohibition of
panel reset
operation
- - 0: Permitted
1: Prohibited
0
H
0736
Prohibition of
change of EOQF
/ HOQF during
operation
- - 0: Permitted
1: Prohibited
1
6.21.1
