E6581158
K-5
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0: H and H
H and H
1: H or H
H and H
2: H and H
H or H
H
0139 Output terminal
logic selection
(RY-RC, OUT-
NO)
--
3: H or H
H or H
0 6.3.3
H
0167 Frequency
command
agreement
detection range
Hz 0.1/0.01 0.0-HJ 2.5 6.3.4
H
0170 Base frequency 2 Hz 0.1/0.01 25.0-500.0 50.0 (WP)
60.0
(WN, AN)
H
0170 Base frequency
voltage 2
Hz 1/0.1 50-330 (200V class)
50-660 (400/600V class)
* 3
H
0172 Torque boost 2 % 0.1/0.1 0.0-30.0 * 1
H
0173 Motor electronic-
thermal protection
level 2
%
(A)
1/1 10-100 100
H
0185 Stall prevention
level 2
%
(A)
1/1 10-199
200 (disabled)
150
6.4.1
*1 : Default values vary depending on the capacity. See the table of page K-14.
*3 : 230 (200V class), 460 (400V class), 575 (600V class)
• Frequency parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0: HOQF (Switchable to H by
terminal input)
H
0200 Frequency priority
selection
--
1: HOQF (Switchable to H at
less than 1.0Hz of designated
frequency)
0 6.5.1
H
0201 VIA input point 1
setting
% 1/1 0-100 0
H
0202 VIA input point 1
frequency
Hz 0.1/0.01 0.0-500.0 0.0
H
0203 VIA input point 2
setting
% 1/1 0-100 100
H
0204 VIA input point 2
frequency
Hz 0.1/0.01 0.0-500.0 50.0 (WP)
60.0
(WN, AN)
6.5.2
H
0207 Frequency setting
mode
selection 2
- - 0: Built-in potentiometer
1: VIA
2: VIB
3: Operation panel
4: Serial communication
5: UP/DOWN from external contact
6: VIA + VIB (Override)
1 6.5.1
