Toshiba TOSVERT VF-S11 User Manual

E6581158
K-3
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
RV
0015 V/F control mode
selection 1
- - 0: V/F constant
1: Variable torque
2: Automatic torque boost control
3: Vector control
4: Automatic energy-saving
5: Dynamic automatic energy-saving
(for fans and pumps)
6: PM motor control
25.11
XD
0016 Torque boost 1 % 0.1/0.1 0.0-30.0 * 1 5.12
VJT
0600 Motor electronic-
thermal protection
level 1
%
(A)
1/1 10-100 100 5.13
6.19.1
Sett ing Overload protection OL stall
0 {
×
1
{{
2
××
3
Standard
motor
×
{
4
{
×
5
{{
6
××
QNO
0017 Electronic-thermal
protection char-
acteristic selection
*2
--
7
VF motor
×
{
05.13
UT
0018 Preset-speed
operation
frequency 1
Hz 0.1/0.01 NN-WN 0.0
UT
0019 Preset-speed
operation
frequency 2
Hz 0.1/0.01 NN-WN 0.0
UT
0020 Preset-speed
operation
frequency 3
Hz 0.1/0.01 NN-WN 0.0
UT
0021 Preset-speed
operation
frequency 4
Hz 0.1/0.01 NN-WN 0.0
UT
0022 Preset-speed
operation
frequency 5
Hz 0.1/0.01 NN-WN 0.0
UT
0023 Preset-speed
operation
frequency 6
Hz 0.1/0.01 NN-WN 0.0
UT
0024 Preset-speed
operation
frequency 7
Hz 0.1/0.01 NN-WN 0.0
5.14
H
- Extended
parameters
- - - - - 4.1.2
ITW
- Automatic edit
function
- - - - - 4.1.3
*1 : Default values vary depending on the capacity. See the table of the page K-14.
*2 : { : valid, × : invalid

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
