Toshiba TOSVERT VF-S11 User Manual

E6581158
F-51
6
[Selection 1: Setting by automatic torque boost]
This is the easiest of the available methods. It conducts vector control and auto-tuning at the same time.
Set the automatic torque boost CW to 
(Automatic torque boost + auto-tuning)
Set the automatic torque boost CW to 
(Sensorless vector control + auto-tuning).
Set the automatic torque boost CW to ҏ
(Energy-saving + auto-tuning)
See Section 5.2 for details of the setting method.
[Selection 2: Setting sensorless vector control and auto-tuning independently]
This method sets sensorless vector control or automatic torque boost, and auto-tuning independently.
Specify the control mode selection parameter (RV) and then set auto-tuning.
Set the auto-tuning parameter H to 
(Auto-tuning enabled)
[Parameter setting]
Title Function Adjustment range Default setting
H Auto-tuning
0: Auto-tuning disabled (use of internal parameters)
1: Application of individual settings of H (after
execution: 0)
2: Auto-tuning enabled (after execution: 0)
0
Set H to .

Toshiba TOSVERT VF-S11 Specifications

General

Model	TOSVERT VF-S11
Category	Inverter
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/f Control, Sensorless Vector Control
Power Rating	0.2kW to 15kW
Cooling Method	Forced air cooling
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	Modbus RTU
Input Voltage	200-240V, 380-480V
Braking Unit	Built-in (optional external braking resistor)
