E6581158
F-65
6
6.19.7 Control mode for small current
H : Small current trip/alarm selection
H
: Small current detection current
H
: Small current detection time
Function
The H parameter allows the inverter to be tripped if a current smaller than the H-
specified value flows for more than the H-specified time. When tripping is selected, enter the
detection time to tripping. Trip information is displayed as "WE".
H=: No tripping (Failure signal FL not activated).
A small current alarm can be put out by setting the output terminal function selection parameter.
H=: The inverter will trip (Failure signal FL activated) if a current below the current set with H
flows for the period of time specified with H.
Title Function Adjustment range Default setting
H
Small current trip/alarm selection
0: Alarm only
1: Tripping
0
H Small current detection current 0-100 (%) 0
H
Small current detection time 0-255 [sec] 0
