Toshiba TOSVERT VF-S11 - Page 21

E6581158
A-9
1
VFS11S-2015, 2022PL
PO
R/L1
PA/＋ PB
S/L2
PC/− U/T1 V/T2 W/T3
M4 screw
Sorting-bar
Grounding terminal
(M5 screw)
Screw hole of EMC plate
Note 1
Grounding capacitor
disconnecting switch
VFS11-4004 ∼ 4037PL
PO
R/L1
PA/＋ PB
S/L2 T/L3
PC/− U/T1 V/T2 W/T3
M4 screw
Sorting-bar
Grounding terminal
(M5 screw)
Screw hole of EMC plate
Note 1
Grounding capacitor
disconnecting switch
