E6581158
K-19
11
Q Table of output terminal functions 3
Function
No.
Code Function Action
35 FCVIBN Inversion of frequency VIB selection Inversion of FCVIB
36 FLR Fault signal (put out also at the time of a retry) ON: When inverter trips or retries
OFF: When inverter does not trip or retry
37 FLRN Inversion of failure signal (put out also at the time
of a retry)
Inversion of FLR
38 OUT0 Specified data output 1 ON: Specified data from remote control FA50:
BIT0= 1
OFF: Specified data from remote control FA50:
BIT0= 0
39 OUT0N Inversion of specified data output 1 Inversion of OUT0 setting
40 OUT1 Specified data output 2 ON: Specified data from remote control FA50:
BIT1= 1
OFF: Specified data from remote control FA50:
BIT1= 0
41 OUT1N Inversion of specified data output 2 Inversion of OUT1 setting
42 COT Cumulative operation time alarm ON: Cumulative operation time is equal to or
longer than H
OFF: Cumulative operation time is shorter than
H
43 COTN Inversion of cumulative operation time alarm Inversion of COT
44 LTA Calculation for life alarm ON: Calculation for life time is equal to or longer
than the preset time
ON: Calculation for life time is shorter than the
preset time
45 LTAN Inversion of calculation for life alarm Inversion of LTA
46 BR Braking sequence output ON: Braking retention signal
OFF: Braking release signal
47 BRN Inversion of braking sequence output Inversion of BR
48 LI1 F terminal input signal ON: The signal input to F terminal is ON
OFF: The signal input to F terminal is OFF
49 LI1N Inversion of F terminal input signal Inversion of LI1
50 LI2 R terminal input signal ON: The signal input to R terminal is ON
OFF: The signal input to R terminal is OFF
51 LI2N Inversion of R terminal input signal Inversion of LI2
52 PIDF Signal in accordance of frequency command ON: Frequency commanded by HOQF or
H and that by VIA show the same
value.
OFF: Frequency commanded by HOQF or
H and that by VIA show different
values.
53 PIDFN Inversion of signal in accordance of frequency
command
Inversion of PIDF setting
54 MOFF Undervoltage detection ON: Undervoltage detected
OFF: Other than undervoltage
55 MOFFN Inversion of undervoltage detection Inversion of MOFF
56-253 Disabled Invalid settings, always OFF (ignored) Invalid settings, always OFF (ignored)
254 AOFF Always OFF Always OFF
255 AON Always ON Always ON
