E6581158
B-5
2
2.2.2 Standard connection diagram 2
MCCB
*1
R/L1
S/L2
T/L3
U/T1
V/T2
W/T3
I M
FLC
FLB
FLA
RY
RC
Motor
P24
F
R
RES
S1
S2
S3
P24
OUT
NO
CC
+
+
-
-
P0
Meter
External potentiometer (1~10kΩ)
(or input voltage signal across VIB-CC terminals: 0-10V)
Control
circuit
Operation panel
Protective function
activation output
VF-S11
Frequency
meter
(ammeter)
Main circuit
Noise
filter
*1: The T/L3 terminal is not provided
for single-phase models.
Use the R/L1 and S/L2 terminal
as input terminals.
*2：The inverter came with the PO
and the PA/+ terminals shorted by
means of a shorting bar.
Before installing the DC reactor (DCL),
remove the bar.
*3: When using the NO output terminal in
source logic mode, short-circuit the P24 and
OUT terminals.
DC reactor (DCL)
*2 (option)
Connector for
common serial
communications
Forward (rotation signal)
Reverse (rotation signal)
Reset
Preset-speed 1
Preset-speed 2
Preset-speed 3
Braking resistor (option)
Standard connection diagram - source (common:P24)
Low-speed
signal output
MCCB(2P)
R/L1
S/L2
Main circuit power supply
200V class: three-phase 200-240V
-50/60Hz
400V class: three-phase 380-500V
-50/60Hz
Power supply
1
φ
200〜240V
-50/60Hz
FM
CC
VIA
VIB
PP
PLC
PA/+
PB PC/-
Voltage signal: 0-10V
(Current signal: 4-20mA)
IISINK
SW1
SOURCE
FM
V
VIA
V
Speed reach signal
output
*3
Ry
