Q Transportation & installation
Danger
See item
Prohibited
• Do not install or operate the inverter if it is damaged or any component is missing.
This can result in electric shock or fire. Please consult your local sales agency for repairs.
Call your local sales agency for repairs.
• Do not place any inflammable objects nearby.
If a flame is emitted due to malfunction, it may result in a fire.
• Do not install in any location where the inverter could come into contact with water or
other fluids.
This can result in electric shock or fire.
1.4.4
1.4.4
2.
Mandatory
• Must be used in the environmental conditions prescribed in the instruction manual.
Use under any other conditions may result in malfunction.
• Mount the inverter on a metal plate.
The rear panel gets very hot. If installation is in an inflammable object, this can result in
fire.
• Do not operate with the front panel cover removed. This can result in electric shock. Fail-
ure to do so can lead to risk of electric shock and can result in death or serious injury.
• An emergency stop device must be installed that fits with system specifications (e.g. shut
off input power then engage mechanical brake). Operation cannot be stopped immediately
by the inverter alone, thus risking an accident or injury.
• All options used must be those specified by Toshiba.
The use of any other option may result in an accident.
1.4.4
1.4.4
1.4.4
1.4.4
1.4.4
Warning
See item
Prohibited
• When transporting or carrying, do not hold by the front panel covers.
The covers may come off and the unit will drop out resulting in injury.
• Do not install in any area where the unit would be subject to large amounts of vibration.
That could result in the unit falling, resulting in injury.
2.
1.4.4
Mandatory
• The main unit must be installed on a base that can bear the unit's weight.
If the unit is installed on a base that cannot withstand that weight, the unit may fall result-
ing in injury.
• If braking is necessary (to hold motor shaft), install a mechanical brake.
The brake on the inverter will not function as a mechanical hold, and if used for that pur-
pose, injury may result.
1.4.4
1.4.4
Q Wiring
Danger
See item
Prohibited
• Do not connect input power to the output (motor side) terminals (U/T1,V/T2,W/T3).
That will destroy the inverter and may result in fire.
• Do not connect resistors to the DC terminals (across PA-PC or PO-PC).
That may cause a fire.
Connect a resistor in accordance with 6.13.4.
• Within ten minutes after turning off input power, do not touch wires of devices (MCCB)
connected to the input side of the inverter.
That could result in electric shock.
2.2
2.2
2.2
