Trackmaster TMX428 - Motor Pan Assembly Wiring

Parts List With Part Numbers Ch. 13 TRACKMASTER
136 TMX428 TMX428CP & TMX58 Service Manual 317-160-406 Rev 4
May 2021
Motor Pan Assembly Wiring
DC MOTOR ASSEMBLY
DC DRIVE MOTOR
CONNECTOR PE,W,V,U
DC DRIVE MOTOR
FEEDBACK CONNECTOR
115V CONFIGURATION 220V CONFIGURATION
RESITOR OMITE
DRIVE DC SERVO PC2303-012-N
BLACK (110-120)
BLANK
BROWN (HOT)
BLANK
BLANK
BLACK (208-240)
BROWN (HOT)
BLANK
WHITE (COMMON)
RED (INCLINE UP)
BLACK (INCLINE DOWN)
CONNET COLOR CONFIGURATION
.250 GAP
CONNECT 2-PIN CONECTOR
BROWN WIRE ON TOP
ORANGE WIRE ON TOP
ITEM 12 SHEET 1 OF 2
CIRCUIT BOARD ASSEMBLY
MULTIPLE GROUND
CONNECTION
DC FAN WIRE RED
DC FAN WIRE BLACK
