Trackmaster TMX428 - Incoming Power Inline Filter Flow Chart 1 B

Troubleshooting Ch. 9 TRACKMASTER
72 TMX428 TMX428CP & TMX58 Service Manual 317-160-406 Rev 4
May 2021
Incoming Power Inline Filter Flow Chart 1B
No
Yes
1B
Verify treadmill power switch
is in the off (0) position.
Verify wire connectors are
secure between power switch
and inline filter.
Is the Green
LED1 lit on
Drive
PC2303-012-N?
No
Turn treadmill power switch in
the on (1) position.
Is the Red D7
LED lit on Smart
Power Supply
FG0495?
No
Yes
Is the Green LED1
lit on Drive
PC2303-012-N?
Is the Red D7 LED
lit on Smart Power
Supply?
Yes
Verify Inline filter continuity
thru filter.
Does the Inline
filter have
continuity?
No
Replace Inline
Filter.
Verify treadmill power switch
is in the off (0) position.
Yes
1C
1D
1C
1D
1C
1D
