TRACKMASTER Ch. 1 Introduction
317-160-406 Rev 4 TMX428 TMX428CP & TMX58 Service Manual 15
May 2021
Table 1: Guidance and Manufacturer’s Declaration – Emissions
The TMX428 Series is intended for use in the electromagnetic environment specified below. The customer
or user of the TMX428 Series should ensure that it is used in such an environment.
Emissions Test
Compliance
Electromagnetic Environment – Guidance
RF Emissions
CISPR 11
Group 1
The TMX428 Series uses RF energy only for its internal
function. Therefore, its RF emissions are very low and are not
likely to cause any interference in nearby electronic
equipment.
RF Emissions
CISPR 11
Class B
The TMX428 Series is suitable for use in all establishments,
including domestic, and those directly connected to the public
low-voltage power supply network that supplies buildings
used for domestic purposes.
Harmonics
IEC 61000-3-2
Class A
Flicker
IEC 61000-3-3
Complies
Table 2: Guidance and Manufacturer’s Declaration – Immunity All ME Equipment and
ME Systems
The TMX428 Series is intended for use in the electromagnetic environment specified below. The customer
or user of the TMX428 Series should ensure that it is used in such an environment.
Immunity Test
IEC 60601
Test Level
Compliance
Level
Electromagnetic Environment –
Guidance
ESD
IEC 61000-4-2
±6kV Contact
±8kV Air
±6kV Contact
±8kV Air
Floors should be wood, concrete
or ceramic tile. If floors are
synthetic, the r/h should be at
least 30%
EFT
IEC 61000-4-4
±2kV Mains
±1kV I/Os
±2kV Mains
±1kV I/Os
Mains power quality should be
that of a typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±1kV
Differential
±2kV
Common
±1kV Differential
±2kV Common
Mains power quality should be
that of a typical commercial or
hospital environment.
Voltage Dips/Dropout
IEC 61000-4-11
>95% Dip for
0.5 Cycle
60% Dip for
5 Cycles
30% Dip for
25 Cycles
>95% Dip for
5 Seconds
>95% Dip for
0.5 Cycle
60% Dip for
5 Cycles
30% Dip for
25 Cycles
>95% Dip for
5 Seconds
Mains power quality should be
that of a typical commercial or
hospital environment. If the user
of the TMX428 Series requires
continued operation during
power mains interruptions, it is
recommended that the TMX428
Series be powered from an
uninterruptible power supply or
battery.
Power Frequency
50/60Hz
Magnetic Field
IEC 61000-4-8
3A/m
3A/m
Power frequency magnetic fields
should be that of a typical
commercial or hospital
environment.
