Trackmaster TMX428 - Motor Pan Assembly Wiring

Parts List With Part Numbers Ch. 13 TRACKMASTER
138 TMX428 TMX428CP & TMX58 Service Manual 317-160-406 Rev 4
May 2021
Motor Pan Assembly Wiring
Item
Description
Part Number
Qty
1
Screw HHWTS #8-32 x .375 Lg
001-1744
4
2
Clamp Plastic ¼” ID
317-160-227
4
3
Harness 110V DC Treadmill
Harness 220V DC Treadmill
317-160-261
317-160-262
1
4
Harness Resistor
417-160-026
1
5
Speed Sensor Hall Effect
Harness Speed Sensor
317-160-305
317-160-306
1
1
6
Harness Elevation
317-160-231
1
7
HH Screw #10-32 x .375 Lg GRD
317-160-076
2
8
Harness Motor Controller
417-160-031
1
9
Harness Ground
317-160-070
2
10
Harness Main DC Treadmill
317-160-247
1
11
Harness Jumper
317-160-071
2
12
LW #10 EXT Tooth
001-1751
1
13
Surge Suppressor
317-160-129
1
14
Decal Ground
317-160-273
1
15
Cable RS232 Panel Mount
317-160-236
1
16
Cable USB Panel to USB B
317-160-237
1
17
Plate RS232 & USB
317-160-254
1
18
HHCS #8-32 x .50 Lg
001-1764
2
19
HNS #8-32 Flange Nut
001-1636
2
20
Decal Caution
317-160-274
2
21
Zip Tie 8” Lg
317-160-280
1
22
Zip Tie 4” Lg
317-160-075
1
23
RMHS #4-40 x .375 Lg
001-2360
2
