Specifications
Directional Orientation
References to left, right, front, and rear are based on the assumption that you are standing on the
treadmill (TMX-428), facing the control console (TMX-428CP). All parts listed below are
considered Patient Applied Parts except where noted.
Item
Description
1
Patient Grab Rails
2
Emergency Stop Button
3
Stop Tether
4
Side Rail
5
Running Belt
6
Elevation Landing Gear (Non-Applied Part)
7
Rear Foot (Non-Applied Part)
2
7
6
2
3
1
4
5
