Operating Instructions Ch.6 TRACKMASTER
40 TMX428 TMX428CP & TMX58 Service Manual 317-160-406 Rev 4
May 2021
Emergency Stop Switch
The emergency stop switch is a safety device for use in emergency situations to stop the
treadmill.
CAUTION: When the Emergency Stop Button (ESB) is engaged or pressed in the closed
position the treadmill’s running belt will coast to a stop.
To release the emergency stop switch, turn the push button ¼-turn in clockwise direction or pull
to release. The treadmill will return to 0.0% elevation.
Emergency Stop Switch Check
NOTE: Verify proper operation of the stop switch assembly every month.
With the belt moving at a relatively high speed, press the emergency stop switch. The
treadmill’s running belt will coast to a stop. To release the emergency stop switch, turn
the push button ¼-turn in clockwise direction or pull to release. The treadmill will return
to 0.0% elevation.
CAUTION: When the Emergency Stop Button (ESB) is engaged or pressed in the
closed position the treadmill’s running belt will coast to a stop.
Use the controlling equipment to terminate the exercise session and turn off the treadmill.
Pull Tether Switch
The pull tether switch is a safety device for patient safety use in emergency situations to stop the
treadmill.
CAUTION: Activation of the pull tether, the treadmill has a controlled deceleration rate of
2.5 MPH per second to 0.0 MPH and held at 0.0 MPH for 3 minutes or until power
cycle.
To re-attach the pull tether, attach clip to the original position on the switch. The treadmill will
return to 0.0% elevation.
Note: The pull tether clip needs to be seated for the treadmill to operate as designed.
Pull Tether Switch Check
NOTE: Verify proper operation of the pull tether switch assembly every month.
With the belt moving at a relatively high speed, pull the wrist strap to activate.
CAUTION: Activation of the pull tether, the treadmill has a controlled deceleration rate of
2.5 MPH per second to 0.0 MPH and held at 0.0 MPH for 3 minutes or until power
cycle.
The running belt will have resistance preventing the free movement of the running
surface. To reattach the pull tether, attach clip to the original position on the switch. The
treadmill will return to 0.0% elevation.
Use the controlling equipment to terminate the exercise session and turn off the treadmill.
