Parts List With Part Numbers Ch. 13 TRACKMASTER
142 TMX428 TMX428CP & TMX58 Service Manual 317-160-406 Rev 4
May 2021
Deck Assembly continued
Item
Description
Part Number
Qty
1
Frame Assembly TMX428
317-Various
1
2
Belt Running with V-Guide
317-160-002
1
3
Bolt HHCS 5/16-18 x .75” Lg
001-1167
6
4
Lock Washer 5/16” Dia
001-1451
7
5
Flat Washer 5/16” Dia
001-1440
9
6
Deck Support Channel Weldment
317-379-001
3
7
Deck Isolator 1.75” Dia with Stud
317-345-003
6
8
Flange Lock Nut HNS 5/16-18
001-1398
6
9
Deck Running Board
317-160-025
1
10
Screw HSFCHCS 5/16”-18 x 1.5” Lg PLTD
001-1739
6
11
Roller Front
317-160-156
1
12
Set Screw 5/16”-18 x 1.75” Lg
317-160-224
1
13
Nut FHNZ 5/16-18 Grade 5
001-1387
1
14
Bolt HSHCS 5/16”-18 x 2” Lg PLTD
001-1748
1
15
Rear Roller
317-160-157
1
16
Belt Tension Plate
317-649-001
2
17
Screw HSHCS 5/16”-18 x 3” Lg PLTD
001-1737
2
18
End Cap LH
317-160-175
1
19
End Cap RH
317-160-176
1
20
Screw HSBHCS 5/16”-18 x 1” Lg PLTD
001-1735
2
21
Extrusion Anti Skid Rubber 60” LG
317-160-055
2
