Parts List With Part Numbers Ch. 13 TRACKMASTER
144 TMX428 TMX428CP & TMX58 Service Manual 317-160-406 Rev 4
May 2021
Final Assembly continued
Item
Description
Part Number
Qty
12
Emergency Stop Assembly RAFI
Emergency Stop Assembly IDEC
317-721-001
317-722-001
1
13
Riv-Nut ¼”-20
001-1686
1
14
Power Cord 110-120 VAC C-19 NEMA 5-15
Power Cord 220-240 VAC C-19 NEMA 6-15
Power Cord 230 VAC C-19 AS/NZS 3112
Power Cord 200-240 VAC C-19 CEE 7/7 EURO
Power Cord 250 VAC C-19 Type N Brazil
Power Cord 230 VAC C-19 UK BS1363
Power Cord 240 VAC C-19 BS546 3 pin Option
Power Cord 250 VAC C-19 Type K Danish
Power Cord 240 VAC C-19 GB1002
Power Cord 250 VAC C-19 Type H Israel
Power Cord 250 VAC C-19 Type L Italy
Power Cord 250 VAC V-19 Type J Swiss
317-160-219
317-160-242
317-160-319
317-160-189
317-160-362
317-160-188
317-160-318
317-160-361
317-160-339
317-160-363
317-160-364
317-160-362
1
15
Decal Hi-Pot Power Cord
317-160-258
1
16
Clamp Support
317-160-092
1
17
Lock Washer ¼”
001-1450
1
18
Bolt HHCS ¼”-20 x ¾” Lg Gr 5
001-2351
1
19
Hood TMX428
317-160-235
1
20
Decal Caution
317-160-018
1
21
Screw HHWHTS #8-32 x 3/8” Lg
001-1744
5
22
Test Plug
317-187-003
1
23
Velcro Hook Backing 1” lg.
317-160-056
1”
24
Velcro Backing 1” Lg.
317-160-057
1”
25
Decal Serial
317-Various
1
26
Decal ETL
317-160-271
1
27
Decal Wheelie Bin
317-160-164
1
