Parts List With Part Numbers Ch. 13 TRACKMASTER
150 TMX428 TMX428CP & TMX58 Service Manual 317-160-406 Rev 4
May 2021
TMX58 Controller Assembly
Item
Description
Part Number
Qty
1
Console Plastic LCD Configuration
317-160-270
1
2
Membrane TMX428 Overlay
317-160-232
1
3
E-Stop Kill Switch LS500
317-160-226
1
4
Harness Jumper Pull Tether
317-160-266
1
5
Board FG0960-0 Console
417-160-017
1
6
RHMS #6-32 3/8” Lg
001-1745
4
7
Harness Communication Jumper
317-160-265
1
8
Back Plate Fitness Panel
317-731-001
1
9
Fastener ¼-20 UNC Riv-Nut
001-1686
4
10
Rubber Control Dampener
317-160-277
2
11
Handrail Controller TMX58
317-714-001
1
12
Flat Washer ¼” Dia
001-1439
4
13
Lock Washer ¼” Dia
001-1450
4
14
Screw BHSCS ¼”-20 x ¾” SS
001-1796
4
15
Polar Board Royal Medical
317-160-221
1
16
Velcro Hook 5/8” x 3” Lg
317-160-056
1
17
Velcro Loop 5/8” x 3” Lg
317-160-057
1
18
Polar Cable 3 pin 12” CA0045
317-160-169
1
19
K-Lock Nut #6-32
001-1823
10
20
Cover Plastic Controller
317-160-234
1
21
Screw HSBHCS 10-32 x ½” Lg
001-2334
4
22
Tether Pull W/Wrist Strap
317-160-229
1
23
Harness Jumper Polar Grip
317-160-267
1
24
Harness Grip ESD
317-390-015
2
25
Grips Polar Kit
317-390-008
1
26
Shim Grip Cap
317-390-013
2
27
Shim Grip
317-390-012
2
28
Fair-Rite Ring 0446164951
317-160-290
1
29
Fair-Rite Ring 0461164281
317-160-291
1
