Introduction Ch. 1 TRACKMASTER
22 TMX428 TMX428CP & TMX58 Service Manual 317-160-406 Rev 4
May 2021
DETAIL 1
Item
Label
Location
Description
1
TMX428 on
center handrail
TMX428CP
center console
Identifies Reading of the
Owner’s Manual
2
Stop on RH or
LH end cap on
handrail
Identifies E-Stop
3
Front of the
device on the
hood
Identifies the Caution
Electrical shock hazard
4
On the motor
Identifies the Caution
Electrical shock hazard
5
On the Power
Cord
Identifies DC Hi-Pot Caution
6
Front of the
device on the
hood
Identifies Master Power
switch.
7
Front of the
device
Identifies Power Off
(disconnection form mains)
and Power On (connection to
the mains)
