9-Transact Template Language Epic Edge™ OEM Integration Manual
100-14444 Rev B August 2018 Page 145
Follow with dynamic text, terminated with [CR]
Setup for city/state/zip field
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<2> Select print mode = 13x24, 14 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<0><85> Set absolute vertical position = 85
[GS]F<0><1><234><3><192> Set field (Left, 490, 960)
Follow with dynamic text, terminated with [CR]
Setup for “GAMING VOUCHER” field
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<1> Select print mode = 12x24, 16 CPI
[GS]!<x33> Select character size = 4W/4H
[ESC]G<1> Set emphasized print
[GS]$<0><170> Set absolute vertical position = 170
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
GAMING VOUCHER[CR] Predefined text, terminate field with [CR]
Setup for “VALIDATION” field
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<3> Select print mode = 14x24, 12 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<1><50> Set absolute vertical position = 306
[GS]F<0><0><200><1><154> Set field (Left, 200, 410)
VALIDATION[CR] Predefined text, terminate field with [CR]
Setup for validation number field
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<3> Select print mode = 14x24, 12 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<1><50> Set absolute vertical position = 306
[GS]F<0><1><164><3><192> Set field (Left, 420, 960)
Follow with dynamic text, terminated with [CR]
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<2> Select print mode = 13x24, 14 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<1><80> Set absolute vertical position = 336
[GS]F<1><0><180><1><144> Set field (Center, 180, 400)
Follow with dynamic text, terminated with [CR]
