9-Transact Template Language Epic Edge™ OEM Integration Manual
100-14444 Rev B August 2018 Page 159
Defining a Region
Below is an example of the commands used to define Region 2 - Validation Number.
Note that the template consists of a series low level printer control codes.
Table 5 Example - User Defined Region 2
Setup for validation field
[GS] M<2> Begin recording Region 2 commands
[ESC]t<0> Set Print Direction in page mode = A
[ESC]!<2> Select print mode = 13x24, 14 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<0><0> Set absolute vertical position = 0
[GS]F<x80><0><100><1><244> Set field (Validation Number field, Left, 100,
500)
Follow with dynamic text, terminated with [CR]
[GS] M<2> End recording Region 2 commands
