9-Transact Template Language Epic Edge™ OEM Integration Manual
Page 144 August 2018 100-14444 Rev B
Predefined Regions
This section contains a list of predefined regions stored in ROM memory in the Epic
Edge™ printer. These predefined regions may be used as is, or redefined using the GS
M command described in Chapter 4. Note that each region is defined by a series of low
level printer commands and that not all regions contain printable data. Refer to the Epic
Edge™ OEM Integration Manual for a complete description of these commands.
Print data for printable regions may be sent from the host or “canned” in the Region
definition. Predefined print data is indicated in the Setup by all capital letters in
parentheses for example: “PRINT DATA”
[ESC]@ Reset to Power-up Condition
[GS]V<1> Set Print Orientation
Setup for validation field
[ESC]t<0> Set Print Direction in page mode = A
[ESC]!<2> Select print mode = 13x24, 14 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<0><0> Set absolute vertical position = 0
[GS]F<x80><0><100><1><244> Set field (Validation Number field, Left, 100,
500)
Follow with dynamic text, terminated with [CR]
Setup for your establishment field
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<3> Select print mode = 14x24, 12 CPI
[GS]!<x11> Select character size = 2W/2H
[ESC]G<1> Set emphasized print
[GS]$<0><60> Set absolute vertical position = 60
[GS]F<1><0><0><3><192> Set field (Center, 0, 960)
Follow with dynamic text, terminated with [CR]
Setup for your location field
[ESC]t<1> Set Print Direction in page mode = B
[ESC]!<2> Select print mode = 13x24, 14 CPI
[GS]!<0> Select character size = 1W/1H
[ESC]G<1> Set emphasized print
[GS]$<0><85> Set absolute vertical position = 85
[GS]F<1><0><0><1><224> Set field (Center, 0, 480)
