5-Electrical Connections Epic Edge OEM Integration Manual
100-14444 Rev B August 2018 Page 39
ServerPort Connection
The Epic Edge™ printer includes a dedicated connection for use with the Transact
ServerPort
e™
module. Harnessing guides are included in the paper bucket to improve
cable retention.
Figure 13 - ServerPort Connection
