5-Electrical Connections Epic Edge OEM Integration Manual
100-14444 Rev B August 2018 Page 35
Interface Connections
The Epic Edge™ printer supports the following communications interfaces through the
universal interface board located at the rear of the printer. .
1. RS232 Serial
2. USB
3. NETPLEX
Communications interface Option 3 – NETPLEX utilizes communications protocols that
are proprietary to specific manufacturers and are subject to licensing requirements. In
this case only the interface pin connections are described in this manual.
Figure 12. Interface PCB Location
