2- Specifications and Requirements Epic Edge OEM Integration Manual
Page 16 August 2018 100-14444 Rev B
Printing Specifications
Print Method: Thermal Sensitive Line Dot System.
Ticket Handling: TicketBurst
TM
ticket buffering with burst.
Print Speed: 125 mm/sec. (5" per sec.) max.
Presentation Speed: 125 mm/sec. (8" per sec.) min.
Resolution: 300dpi x 300dpi.
Dot Pitch-Horizontal: 0.085 mm (11.4 dots/mm).
Dot Pitch-Vertical: 0.085 mm (11.4 dots/mm).
Line Feed Pitch: 3.2 mm (.125").
No. of Elements: 712 dots in-line.
Print Width: 62.5 mm (2.46").
Ticket Specifications
Ticket Width: 65 ± 1mm (2.56" ± .03").
Ticket Lengths: 156 ± 1mm (6.14" ± .04")
or
120 ± 1mm (4.72 ± .04” with short ticket adapter.
Ticket Thickness: 4.5-5.0 mils (.114-.127 mm).
Ticket Weight: 27# (102 g/m) Avg.
Brightness
:
89% Ave. (84%Min.), Test method TAPPI T-525
Printing Colors: Black (visible light absorption: 600 ~ 700 nm)
Quantities Available: Fan-folded stacks of 200, 400, 800 tickets.
Contract Transact for complete ticket specifications and approved suppliers
Bar Code Specifications
Standard Bar Code: Interleaved. 2 of 5*
Minimum Bar Width: 0.5 mm min./0.6 max.
W : N Ratio: 3 : 1 (recommended, with 12:4 wide bar width (dots):narrow bar
width (dots)).
# of Characters: 6 min./18 max.
Symbol Contrast Value: 70% min.
Applicable Standards: ANSI X3.182
gsa-p0038.001.01
*Contact Transact for information on additional supported bar codes
