TransAct Printrex 980 - Page 144

Appendix B: Frequently Asked Questions
Page 134 100-11672 - Rev D
Misregistration (Leading edge and side edge)
Cause
Procedure
Check Item
Action
Paper
1
Dedicated paper is not used.
Replace with
dedicated
paper.
2
Paper is not loaded properly.
Load paper
properly.
Paper Setup
3
The type and size of paper used are not
set properly.
Properly set the
type and size of
paper used.
Margin Setup
4
Margins are not set to appropriate
values.
Set margins to
appropriate
values.
Inter-label
Gap and TOF
Mark Setup
5
The inter-label gap or TOF mark width is
not set to a value suitable for paper
used.
Set the inter-
label gap or
TOF mark width
to a value
suitable for
paper used.
Position
Adjustment
6
Carry out image position adjustment,
and then check that the defect has been
recovered.
End
TOF Sensor
7
TOF Sensor is contaminated with paper,
dust, etc.
Clean TOF
Sensor.
8
TOF Sensor is not operating properly.
Replace TOF
Sensor.
Paper Skew
Cause
Procedure
Check Item
Action
Paper
1
Paper is not loaded properly.
Load paper
properly.
Roll Drive
Unit
2
Roll Drive Unit is not installed properly.
Reinstall it
properly.
Guide Unit
3
Guide Unit is not installed properly.
Reinstall it
properly.
Pinch Roller
Unit or Spur
Unit
4
The unit is not installed properly.
Reinstall it
properly.
5
Pinch Roller or Spur does not rotate
smoothly.
Replace Pinch
Roller Unit or
Spur Unit.
Transport
Unit
6
Transport Belt is not located at the
correct position
Move Transport
Belt back to the
correct position.
Roll Drive
Unit
7
Replace Roll Drive Unit, and then check
that the defect has been recovered.
End
Guide Unit
8
Replace Guide Unit, and then check that
the defect has been recovered.
End
Transport
Unit
9
Replace Transport Unit, and then check
that the defect has been recovered.
End
