Appendix B: Frequently Asked Questions
Page 198 100-11672 - Rev D
Code
Detail Code
Item
Description
09
51-5B
(MODULE1)
D1-DB
(MODULE2)
*3
Condition
Detected
Supply Valve status error when driving Pump
(dragging)
Action
1. Restart Printer in service mode, and then
load ink.
Service Utility > Troubleshooting > Ink Loading
2. Check the leakage of ink pass.
3. Replace Print Module.
4. Replace Printer Controller PCB.
09
61-6B
(MODULE1)
E1-EB
(MODULE2)
*3
Condition
Detected
Bubble Removing Valve status error when
driving Pump (dragging)
Action
1. Restart Printer in service mode, and then
load ink.
Service Utility > Troubleshooting > Ink Loading
2. Check the leakage of ink pass.
3. Replace Print Module.
4. Replace Printer Controller PCB.
09
71-7B
(MODULE1)
F1-FB
(MODULE2)
*3
Condition
Detected
Bubble Removing Valve status error when
driving Pump (dragging)
Action
1. Restart Printer in service mode, and then
load ink.
Service Utility > Troubleshooting > Ink Loading
2. Check the leakage of ink pass.
3. Replace Print Module.
4. Replace Printer Controller PCB.
09
Remarks
*1: The low-order 4 bits are 2: BK, 3: C, 4: M, 5:Y.
*2: The low-order 4 bits are 6: BK, 7: C, 8: M, 9:Y.
*3: The low-order 4 bits represent the Pump drive type.
1: Driven without sensor detection
2: Driven on Ink Level Sensor detection (BK)
3: Driven on Ink Level Sensor detection (C)
4: Driven on Ink Level Sensor detection (M)
5: Driven on Ink Level Sensor detection (Y)
6: Driven on Ink Level Sensor detection (BK)
7: Driven on Ink Level Sensor detection (C)
8: Driven on Ink Level Sensor detection (M)
9: Driven on Ink Level Sensor detection (Y)
A: Pressure Sensor under detection
B: Pressure Sensor excess detection
0F: Printer Overheat
0F
01-FF
(Additional
value of
K:01,C:02,
M:04,Y:08)
(MODULE1),
(Additional
value of
K:10,C:20,
M:40,Y:80)
(MODULE2)
Condition
Detected
Printheads are overheated. If used further,
Printheads will be damaged.
Action
Replace Printheads.
