Appendix A: Ordering Genuine Ithaca Supplies
100-11672 - Rev D Page 201
Code
Detail Code
Item
Description
M:40,Y:80)
(MODULE2)
20: Upper Life Limit Sensor Error
20
01
Condition
Detected
Feeder Tray does not move correctly.
Feeder Tray Unit moves up and then Upper Lift
Limit
Sensor does not detect.
Action
1. Check Upper Lift Limit Sensor connection.
2. Check Paper Lift Motor connection.
3. Check Lift Unit movement.
4. Replace Upper Lift Limit Sensor.
5. Replace Paper Lift Motor.
6. Replace Lift Unit.
7. Replace Printer controller PCB.
20
02
Condition
Detected
Feeder Tray does not move correctly.
Feeder Tray Unit moves up and then Upper Lift
Limit
Sensor does not detect.
Action
1. Check Upper Lift Limit Sensor connection.
2. Check Paper Lift Motor connection.
3. Check Lift Unit movement.
4. Replace Upper Lift Limit Sensor.
5. Replace Paper Lift Motor.
6. Replace Lift Unit.
7. Replace Printer controller PCB.
21: Lower Life Limit Sensor Error
21
01
Condition
Detected
Feeder Tray does not move correctly.
Feeder Tray Unit moves up and then Lower Lift
Limit
Sensor does not detect.
Action
1. Check Lower Lift Limit Sensor connection.
2. Check Paper Lift Motor connection.
3. Check Lift Unit movement.
4. Replace Lower Lift Limit Sensor.
5. Replace Paper Lift Motor.
6. Replace Lift Unit.
7. Replace Printer controller PCB.
21
02
Condition
Detected
Feeder Tray does not move correctly.
Feeder Tray Unit moves up and then Lower Lift
Limit
Sensor does not detect.
Action
1. Check Lower Lift Limit Sensor connection.
2. Check Paper Lift Motor connection.
3. Check Lift Unit movement.
4. Replace Lower Lift Limit Sensor.
5. Replace Paper Lift Motor.
6. Replace Lift Unit.
7. Replace Printer controller PCB.
24: Climate Sensor Not Connected
