TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 73 Copyright 2013 All Rights Reserved.
 TEXT
Description
This command prints text on label.
Syntax
TEXT x,y,"font",rotation,x-multiplication,y-multiplication,[alignment,]"content"
Parameter
Description
x
The x-coordinate of the text
y
The y-coordinate of the text
font
Font name
0
Monotye CG Triumvirate Bold Condensed, font
width and height is stretchable
1
8 x 12 fixed pitch dot font
2
12 x 20 fixed pitch dot font
3
16 x 24 fixed pitch dot font
4
24 x 32 fixed pitch dot font
5
32 x 48 dot fixed pitch font
6
14 x 19 dot fixed pitch font OCR-B
7
21 x 27 dot fixed pitch font OCR-B
8
14 x25 dot fixed pitch font OCR-A
ROMAN.TTF
Monotye CG Triumvirate Bold Condensed, font
width and height proportion is fixed.
Following fonts were supported since V6.80 EZ.
1.EFT
EPL2 font 1
2.EFT
EPL2 font 2
3.EFT
EPL2 font 3
4.EFT
EPL2 font 4
5.EFT
EPL2 font 5
A.FNT
ZPL2 font A
B.FNT
ZPL2 font B
D.FNT
ZPL2 font D
E8.FNT
ZPL2 font E8
F.FNT
ZPL2 font F
G.FNT
ZPL2 font G
H8.FNT
ZPL2 font H8
GS.FNT
ZPL2 font GS
rotation
The rotation angle of text
0 : No rotation
90 : degrees, in clockwise direction
180 : degrees, in clockwise direction
270 : degrees, in clockwise direction
x-multiplication
Horizontal multiplication, up to 10x
Available factors: 1~10
For "ROMAN.TTF" true type font, this parameter is ignored.
For font "0", this parameter is used to specify the width (point) of true type
font. 1 point=1/72 inch.

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
