TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 118 Copyright 2013 All Rights Reserved.
 OPEN
Description
This command opens a downloaded file and establishes the file handle. Up to two file handles are
supported, thus only up to two files can be opened simultaneously. The file to be opened should be
downloaded prior to using this command. When opening a file, the firmware will search automatically
to see if the file exists in the on board flash memory or extended memory card. *Since V6.37 EZ, if the
file doesn’t exist, the printer will create this file in the onboard FLASH.
Syntax
OPEN [memory ID,]"filename",file handle
Parameter
Description
[memory ID]
Optional. Open the file in specific memory device. *Since V6.68 EZ.
ID
Memory device
Omitted
DRAM
F
FLASH
E
CARD
filename
The file downloaded in the printer memory
file handle
Either 0 or 1
Example
Sample code
DOWNLOAD "DATA.DAT",18,Open file in DRAM.
DOWNLOAD F,"DATA.DAT",19,Open file in FLASH.
DOWNLOAD "TEST.BAS"
data1$=""
data2$=""
data3$=""
OPEN "DATA.DAT",0
READ 0,data1$
CLOSE 0
OPEN F,"DATA.DAT",0
READ 0,data2$
CLOSE 0
KILL F,"*"
OPEN "NEW.DAT",0
SEEK 0,0
WRITE 0,"Auto create a new file in FLASH."
SEEK 0,0
READ 0,data3$
CLOSE 0
SIZE 4,1
GAP 0,0
CLS
TEXT 10,10,"3",0,1,1,data1$
TEXT 10,60,"3",0,1,1,data2$
TEXT 10,110,"3",0,1,1,data3$
PRINT 1
EOP
TEST
Result

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
